LKV344 4X4 HDMI Matrix Switch is a full routing type 4-by-4  HDMI Matrix Switch, and any one of input sources is able to be displayed  simultaneously on 4 displays.

It offers HD video solution for super market; shopping Mall;  HDTV, STB, DVD and projector factory; data control center; information  distribution; conference room presentation; education and training, corporation  show room, luxurious house, etc.

Features

-It is real HDMI 1.3 version and HDCP compliant;

-Support full HDMI resolutions 1080p, 1080i, 720p, 720i and standard video  format;

-Multiple Switching modes: IR remote control, operate manually or  operate via RS232 port;

-With IR extender: enlarge remote control signal;

-Rack-mountable: with mounting kit and screws;

-Input video signal:  0.5-1.0 volts p-p;

-Input DDC signal: 5 volts p-p (TTL);

-Audio:  LPCM,Dolby-AC3, DTS7.1, DSD/Dolby TrueHD/DTS-HD master Audio;

-HDMI video  color format: deep color;

-Maximum transmission distance: 10 meters by 28AWG  cable; 15 meters by 26AWG cable(for further distance, HDMI extender is  optional);

-Power consumption: MAX. 36W;

-Power supply: 12V DC,  3A

Connection Image

Interface Specification

Front:

1.Power  input                         2.4 HDMI Outputs

3.4 HDMI  Inputs                     4.IR extension

5.RS232 port1.Power  input

Back:

1.Output1 selection                                  2.Output1 LED

3.Output2 selection                                 4.Output2  LED

5.Output3 selection                                 6.Output3  LED

7.Output4 selection                                 8.Output4 LED

9.IR  Receiving window.                         10.Key lock button

11.LED Indicator  of locking status      12.Power Switch

Accessories & Package

Item
Qty
Pic
IR Extender
1 pcs
RS232 Control Software
1 pcs
Power supply
1 pcs
Remote Controller
1 pcs
User manual
1 pcs
Package Box
1 pcs
